Digital Recorder

Main monitor display modes

Full screen, quad, 9-way and 16-way split (16 camera
models only)

Auto Sequencing

1-99 seconds, full and quad, main and spot monitors

Covert (hidden)

any cameras may be hidden from view on the monitors

1.1.45 Control

and

Interface

Standard Keypad

35 single function keys (Vi-M2, Vi-M3 and Vi-M4)

Mini Keypad

14 single and 2 dual function keys (Vi-M1)

Remote keyboard Inputs

RJ45, RS485, 9600-baud (1 start, 8 data, 1 stop) data, with
built-in balun for twisted pair video connection to remote
keyboards with attached monitors.

Spot monitors

4 camera models – no spot monitor output is available

8 camera models – 1 spot monitor

12 camera models – 2 spot monitors

16 camera models – 3 spot monitors

Passwords

4 passwords with fully programmable rights. Also
programmable rights when not logged on.

Search modes

Date/time search, sweep, alarm, system and cricical event
log

Timers

Alarm and activity (by hour for weekdays and weekend)

Audio

Dual channel audio, 8kHz bandwidth

Line input/output

3.5mm stereo jack connectors, -30dB level, 47k Ohms

Audio sensitivity control

30db range, via menu

Alarm inputs

16 inputs, suit normally open or normally closed volt-free
contacts, inputs mapped

Activity detection

16 x 12 zones, programmable sensitivity

Relays 2

relays

Relay Contact Rating:

24Vdc, 200mA max normally open or closed

Alarm/activity response

Pull-up full screen display, maximum record rate

Events logs

Alarms, System, Critical

Incident list

Up to 10 incidents may be saved onto one DVD, CD or USB
memory stick

Watchdog timer

In the event of any unexpected condition, the system will
automatically restart

1.1.1.40

Dome Control

Interfaces

RS485 (x2), Up-the-Coax (x16)

Telemetry (coax)

BBV

Telemetry (twisted pair)

RS485, RS232 and 20mA. Protocols include Videoswitch
VXP-4, JVC, VCL, BBV, Dennard, Sanyo, Samsung,
Forward Vision, Mercer, Molynx/Bewator, Merit-LiLin,
Borsatec, Pelco-D
