Digital Recorder
7 Help
• On a mini-keypad, Help is access by pressing SEL to enter the root menu, then
using up and down to select the required row, followed by SEL
• On a standard keypad, Help may be accessed directly by pressing the HELP key
7.1 Status/Config
1.1.32 Config
This is an example of the config screen, which shows the configuration of the DVR.
Press left or right to see other help screens.
Config
Model Vi-M316 (16 cameras)
Cards fitted CM- C-- CM- C-- ---
Capacity 992 Gbytes
Serial number 00298350
Firmware ID 1818
Logic ID 7
Unit number None
IP address 192.168.16.67
MAC address 00:00:49:09:1A:DC
Ethernet 100 Mb/s HDX
1.1.33 Status
This is an example of the status screen which shows the status of video, alarms, activity
etc.
Press left or right to see other help screens.
Status
Video ################
Alarms ----------------
Activity ----------------
Relay timer ----------------
Relays --
Load [= ]
Temperature 49C
MMC status OK
