54 Installation and Programming Manual
Appendix D: Specifi cations
Electromagnetic Rating: IEC 801-2, Level 3
(Electrostatic discharge requirements)
IEC 801-4, Level 3
(Electrical fast transient/ burst requirements)
Humidity: 5% to 95%, noncondensing
Memory Retention Time: Maintains programmed values for 10 years without power.
Movement Input: 85-265 VAC (rms), 12 mA maximum; optical isolated to
3200 VDC and 2250 VAC.
Analog:
Output Settings: 2 channels independently confi gurable for Voltage or
Current output.
Resolution:
Voltage Resolution Approx. 300µV
Current Resolution Approx. 0.300 µA
Update Period:
For confi gurations
without Digital Outputs: Position:
5mS
Rate: 10 mS
For confi gurations
with Digital Outputs: Position:
20 mS
Rate: 10 mS
Non Linearity:
T = 25 C: ± 915 µV
± 0.915 µA
Output Drift: Less than ±30 ppm/°C
Voltage 100 µVolt/°C typical
Current 0.10 µAmp/°C typical
Output Isolation: None
Output Loading:
Voltage ±10V into a 1K
Ω
load (±10mA max)
Current 0 mA to 20 mA sourcing into a 750
Ω
load (15V max)
