14
Installation and Programming Manual
Chapter 3: Mounting and Wiring
Analog Output (FMOA01) Output Option A1
The Analog Output board provides two channels of analog output that can be independently
confi gured and scaled. Each channel can be confi gured for an output based upon position or
velocity. Velocity will be RPM if the sensor is a resolver or inches/mm per second if the input
sensor is an LDT. The two channels of analog output allow you to confi gure one analog output
to be based on position while the other channel provides a simultaneous indication of velocity.
Figure 3-8 Pinout Diagram Digital Output
Drawing E8002099
Terminal Wire Size: No. 22-12 AWG
Figure 3-9 Pinout Diagram Analog Output
Drawing E8005099
P
T
U
O
T
U
L
T
D
G
PIN13
PIN25
PIN1
PIN14
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
23
25
24
IN
IN
21
22
20
19
18
17
16
DATA OUT BIT 5
DATA OUT BIT 7
DATA OUT BIT 9
DATA OUT BIT 11
DATA OUT BIT 13
SYNC
VSRC+
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
DIRECTION
8
12
IN
15
14
13
IN
10
11
9
6
7
5
4
3
2
1
PIN
DATA OUT BIT 1
DATA OUT BIT 3
DATA OUT BIT 12
DATA OUT BIT 10
DATA OUT BIT 8
DATA OUT BIT 6
DATA OUT BIT 4
DATA OUT BIT 2
DATA OUT BIT 0
BUS ENABLE*
BUSY*
GND
DESCRIPTION
DATA OUT BIT 14/INCREMENTAL OUT Z*
DATA OUT BIT 16/INCREMENTAL OUT A*
DATA OUT BIT 18/INCREMENTAL OUT B
DATA OUT BIT 15/INCREMENTAL OUT B*
DATA OUT BIT 17/INCREMENTAL OUT Z
DATA OUT BIT 19/INCREMENTAL OUT A
5
1
ANALOG
4
23
8
67
FMOA01
CH1 VDC OUTPUT
CH1 VDC GROUND
CH1 CURRENT OUT
CH1 CURRENT RETURN
CH2 VDC OUTPUT
CH2 VDC GROUND
CH2 CURRENT OUT
CH2 CURRENT RETURN
