AMETEK 2120 PLC Interface Module User Manual

Page 13

background image

Installation and Programming Manual

Chapter 3: Mounting and Wiring

9

Figure 3-1 Dimensional Drawing

Drawing E0232200

AUX 3

AUX 2

AUX 1

PROGRAM

FLT OK

MVT FLT

POSITION

UPR LIM
LWR LIM

RPM

2120

SERIES

2.67

2.61

3

.0

0

2

.0

0

T

Y

P

6.50

5.32 CASE WIDTH

6.00

5.38

.50

5.53

RECOMMENDED

PANEL CUTOUT

MOUNTING RAIL W/ FOOT

ALUMINUM CASE

3/8 DIN STD

ALUMINUM BEZEL

1/8" GASKET

DEPLUGGABLE

TERMINAL STRIPS

F

( )

MOUNTING RAIL FOOT

MOUNTING SCREWS
