AMETEK 2120 PLC Interface Module - Manual (Page 15)

Installation and Programming Manual
Chapter 3: Mounting and Wiring
11
Figure 3-3 Relay Output Pinout Diagram
Figure 3-4 Power Supply Pinout Diagram
Power Supply Module (FMPS01)
The power supply module has a main power input, an auxiliary input, and a fault check output.
(See Figure 3-4). Power input: 85-265 VAC at 450 mA maximum. Fault check output: 8 amps
250 VAC, 30 VDC, 1/4 HP 125, 250 VAC. It is recommended that the fault check contacts be
connected to the required safety interlock. Auxiliary input: 85-265 VAC at 12 mA maximum.
The terminal wire size for all connectors is No. 22-12 AWG. See page 3, 15 and 16 for use of
this special purpose input, concerning position hold and move detection.
LOWER LIMIT
UPPER LIMIT
RELAY 2
RELAY 1
FMOR01
{
NC
NC
NC
NO
NO
NC
{
NO
NO
3
68
7
5
4
RELAY
2
1
FAULT
CHECK
AUXILIARY
INPUT
POWER
INPUT
{
GND
L1
L2
NO
NO
{
L2
L1
3
6
7
5
4
2
1
POWER SUPPLY
100-240VAC 50/60Hz
FMPS01
L1
L2
GND
FLT CHK
AUX INP
{
{
{
