Appendix B: Function Summary Chart
This Appendix contains three function summary charts: B-1: General Function Summary, B-2
Resolver Specifi c Function Summary, and B-3: LDT - Specifi c Function Summary. The
General Function Summary contains function summaries which apply to both a resolver and
LDT based system.
Function Number Function Name Description
10 Program Mode Access
This function is used to put the monitor in either pro-
gram or supervisory mode.
11 Program Mode Time-Out
This function is used to change the duration of time the
monitor will stay in program mode once the Program
Mode Access function is entered.
12
Move Detection Time-Out
and/or the position Hold’s
dwell time
This function is used to program the time the Interface
Module must move within when power is applied to
the move detection input. This function also can be
used to program the Position Hold function’s dwell
time.
13 Decimal Location
This function is used to program the resolution of the
Interface module and all position data shown on the
monitor’s LED display.
14 Unit of Measurement
This function is used to select the unit of measurement
for the Interface Module and all position data.
15 Position Hold
This function is used in applications where it is neces-
sary to stop the monitor from updating the Interface
Module display during periods of high vibration.
16 Auxiliary LED
This function is used to enable the monitor’s auxiliary
LED.
90 New Access Code
This function is used to change the current program
mode access code.
400 Upper End Limit
This function is used to program the upper end limit of
the Interface Module opening.
401 Lower End Limit
This function is used to program the lower end limit of
the Interface Module opening.
402 Relay State
This function is used to program the monitor’s upper
and lower limit relays to either energize or de-energize
when the monitor is in normal machine operation.
