Installation and Programming Manual
Chapter 4: Programming
25
NOTE: The Interface Module is defaulted to stay in program mode for 120 seconds. The
monitor will drop out of program mode if a key is not pressed within this time. If this
occurs, you will have to repeat steps 1-3. Further, the access code (2100) is provided
initially. This code can be changed through the use of the New Access Code function.
For security reasons, this function can only be implemented when the monitor is in
supervisory mode. For more information on, New Access Code, contact the factory.
4. Select the function key.
The monitor displays “F-----”.
5. Select function number 300 (Scale Factor function). Select the enter key.
The monitor displays currently programmed scale factor.
6. Enter the desired scale factor value, including digits up to a maximum of three
spaces to the right of the decimal point. Select the enter key.
Adjust the Turns Counting Factor (301)
7. Select the function key.
The monitor displays “F-----”.
8. Select function number 301 (Turns Counting function). Select the enter key.
The monitor displays currently programmed turns counting factor
9. Enter desired number of turns to reach scale factor. Select enter key.
10. Select Function Key.
The monitor displays “F----”.
11. Select Function 308 (Wrap Around Feature). Select enter key.
The monitor displays 0 or 1.
0 = Wrap Around Disabled
1 = Wrap Around Enabled
300
301
Number
of Turns
308
Select Wrap Around Feature (308)
12. Enter 0 or 1. Select enter key.
Enter 0 or 1
(F)
(F)
(F)
