CDN IN428 - Infrared Thermometer EN - Manual (Page 3)

C. Battery Status
The thermometer incorporates visual battery
status indication:
1.
Battery OK: measurements are possible
2. Battery Low: replace battery with a
CR2032 lithium cell; measurements are
possible
3. Battery Exhausted: replace battery;
measurements are not possible
Care of Your Product
• The sensor lens is the most delicate part of the
thermometer and should be kept clean at all times.
Take care when cleaning the lens. Use only a soft
cloth or cotton swab with water or rubbing alcohol.
Allow the lens to fully dry before using
the thermometer.
• Do not submerge any part of the thermometer
in water. Wipe clean with a damp cloth.
• Store the thermometer at room temperature
between -4 to +149°F/–20 to +65°C.
Precautions
• Dispose of used battery promptly and keep away
from children.
• Do not clean the case with abrasive or corrosive
compound, which may scratch the plastic and
corrode the electronic circuits.
• Do not subject the unit to excessive force shock,
dust, temperature or humidity, which may result in
malfunction, shorter electronic life span, damaged
battery and distorted parts.
• Do not tamper with the unit’s internal components.
Doing so will invalidated the warranty on the unit
and may cause unnecessary battery damage and
distorted parts.
• Do not subject the unit to excessive exposure to
direct sunlight. The unit is not waterproof — do
not immerse it into water or expose to heavy rain.
• To avoid deformation, do not place the unit in
extreme temperatures.
• Always read the users manual thoroughly before
operating.
Specifications
Measurement Range -67 to +428°F/-55 to +220°C
Operating Range
14 to +122°F/-10 to +50°C
Resolution 0.1°F/°C (selectable)
Response Time 1 second
Accuracy ±1.1°F/±0.6°C
(Tobj=59~95°F/15~35°C,
Tamb=77°F/25°C)
Accuracy
±2% of reading or 4°F/2°C
(Tobj=-27~428°F/-33~220°C, whichever is greater
Tamb=73±37.4°F/23±3°C)
Distance:Spot
1:1 optics ratio
Emissivity Range 0.95 default;
adjustable 0.05 to 1 step .01
Battery Life Typ. 40 hr, min 30 hr
(auto power off after
15 seconds)
Power Supply 1 CR2032 lithium battery
Dimensions 1.5 W x 3.0 H x 0.75 D
(inches)/
39.0 W x 76.8 H x 19.3 D
(mm)
Weight 1.12 oz/32 g
(including battery)
CAUTION: Avoid keeping the thermometer too close to objects
that continuously generate high heat for long periods (i.e., hot
plate). This can cause the thermometer to overheat.
© 2006 Component Design Northwest, Inc. Made in China CD9999187en - 11/06 EHC 614 885-2497
��������� ������ ���������� ����
�� ��� �����
��������� �� ����������
��� ��� ��������
��� ��� ��������
��� �����������������������
The information in this document has been reviewed and is
believed to be accurate. However, neither the manufacturer nor
its affiliates assume any responsibility for inaccuracies, errors
or omissions that may be contained herein. In no event will
the manufacturer or its affiliates be liable for direct, indirect,
special, incidental or consequential damages arisen by using
this product or resulting from any defect/omission in this
document, even if advised of the possibility of such damages.
The manufacturer and its affiliates reserve the right to
make improvements or changes to this document and the
products and services described at any time, without notice
or obligation.
1-Year Limited Warranty: Any instrument that
proves to be defective in material or workmanship
within one year of original purchase will be repaired
or replaced without charge upon receipt of the
unit prepaid at: CDN, PO Box 10947, Portland, OR
97296-0947. This warranty does not cover damage
in shipment or failure caused by tampering, obvious
carelessness or abuse
*USDA does not endorse any product, service or organization.
