CDN DTQ450X - ProAccurate® Thermometer EN - Manual

Perfect For
• Thin cuts of meat, fish or poultry
Easy To Use
• 6 second response
• Data-hold
• Big digit
• Temperature guide on sheath
Features
• NSF ® Certified
• 1.5 mm thin tip
• 5"/12.7 cm stem
• Waterproof
• Shatterproof
• Food-safe ABS plastic with BioCote ®
• Stainless steel stem
• Field calibration
• On/off button
• Auto-off after 10 minutes
• Sheath can be used as handle extension
• Mounting: pocket clip
• Battery & instructions included
Note: Remove sticker from display before use.
Note: In the following instructions, names of the control
buttons are shown in CAPS. Function information that appears
on the display is shown in BOLD CAPS.
Battery Installation
The battery is installed. Replace battery when LCD
becomes dim.
1. Remove battery cover on the front with a coin.
2. Install one LR44 battery with positive (+) side up.
3. Replace the battery cover.
Operating Instructions
A. Temperature Measurement
1. Press the ON/OFF button to turn the
DTQ450X on.
2. After use, press the ON/OFF button to turn
the DTQ450X off and conserve battery life.
The DTQ450X automatically turns off after
10 minutes of inactivity.
B. Temperature Scale
Press the °F/°C button to select temperature
reading in Fahrenheit or Celsius.
C. Data-Hold
Before withdrawing the DT450X from the food,
press the HOLD button. This will “hold” the
reading until pressed again. HOLD appears in the
upper right corner of the display.
D. Max Mode
Max Mode is always working behind the scenes,
continually storing the highest temperature.
1. Press the MAX button to display the highest
temperature. MAX appears on the display.
2. The display automatically returns to the
temperature mode after a few seconds.
3. Press the MAX button for 3 seconds or more to
clear the stored MAX value.
Model: DTQ450X
ProAccurate ® Thermometer
-40 to +450°F/-40 to +230°C
