0040506000 1811 Page 7
Operating and installation instructions
Electric thrust actuator ARI-PACO 0,85 kN
4.4 Technical data - Remarks
Type ARI-PACO
Thrust kN 0,85 D 0,85 Y
Travel max. mm 3 ... 20
Control speed mm/sec. 0,11
Motor voltage ( ±10% ) 230V - 50 / 60Hz* 24V - 50 / 60Hz*
Control signal (input) Three-step signal
0 (2) - 10 V DC
(invertable, max. 0,5 mA)
Feedback signal (output) --
0 - 10 V DC
(invertable, max. 5 mA)
Power consumption VA 4,1 4,8
Operation mode S3 50% cyclic duration factor
Enclosure IEC 60529 IP 54
Max. operative ambient temperature 0 °C ... +50 °C
Handwheel Change-over switch and handwheel
Mounting position Horizontally to vertical above the valve body (any position 90° from vertical)
Stem lubricant Klüber: Microlube GB
Weight kg 1,3
* Control speed and power consumption are 20% higher at frequency of 60 Hz.
Accessories
Additional torque switches
2 changeover contacts, potential-free,
switching capacity 3A, 250 V~
--
Switch board
(optional as 2 add. torque switches or
1 error message switch usable)
--
2 changeover contacts, potential-free,
switching capacity 3A, 250 V~
Potentiometer 1 pc. - 1000 Ohm
1 pc. - 1000 Ohm
(alternative to
switch board)
Additional voltages/frequencies 24 V 50/60* Hz --
* Control speed and power consumption are 20% higher at frequency of 60 Hz.
