Operating and installation instructions
Electric thrust actuator ARI-PACO 0,85 kN
6.2 Putting the actuator into operation ARI-PACO 0,85 Y
Automatic operation without housing:
- For safety reasons, the actuating drive switches over to manual operation when the
housing is removed.
- For function testing during commissioning, the drive can be switched to automatic
operation with the magnet switch A.
Fig. 29
ATTENTION !
- Before commissioning, check the correct insertion of the valves, as well as the
electrical connection.
Fig. 30
Manual
Automatic
