Operating and installation instructions
Electric thrust actuator ARI-PACO 0,85 kN
5.2 Manual operation
5.2.1 ARI-PACO 0,85 kN
For the manual operation, the sliding switch above the housing must be switched to
manual.
Fig. 4
Proceed as follows:
- Turning clockwise
--> coupling moves in
- Turning counter-clockwise --> coupling moves out
On reaching the end positions, a slip coupling prevents further actuating force.
ATTENTION !
- Since the hand wheel always turns during motor operation (running display),
never use manual operation when the motor is running - danger of injury!
Automatic Manual
