ACCESSORIES
MODEL NO. DESCRIPTION PART NUMBER
CCBRPG
10-Pin MS Connector CCBRPG04
10-Pin MS Connector with 10 ft 24 AWG
9 Conductor Cable w/drain
CCBRPG05
10-Pin MS Connector with 20 ft 24 AWG
9 Conductor Cable w/drain
CCBRPG06
RPGBSI
0.500 Inch Bore Sleeve RPGBSI00
0.625 Inch Bore Sleeve RPGBSI01
0.750 Inch Bore Sleeve RPGBSI02
0.875 Inch Bore Sleeve RPGBSI03
RPGBSM
19 mm Bore Sleeve RPGBSM00
20 mm Bore Sleeve RPGBSM01
24 mm Bore Sleeve RPGBSM02
25 mm Bore Sleeve RPGBSM03
RPGMK
Standard Tether Arm Kit 4.5 Inch RPGMK002
Elongated Tether Arm Kit 8.5 Inch RPGMK003
RPGMB * Magnetic Coupling Kit (0.625 inch shaft) RPGMB001
RPGPC 56C Protective Cover RPGPC000
* ZUL encoders require 0.625 " bore sleeve to accomodate magnetic coupling.
ORDERING INFORMATION
MODEL NO.
0.625" Thru-Bore Rotary Pulse
Generators For Motor Feedback
1024 ZUJ1024Z
2048 ZUJ2048Z
DESCRIPTION
1024 ZUL1024Z
PPR PART NUMBER
2048 ZUL2048Z
ZUL
ZUJ
1" Thru-Bore Rotary Pulse
Generators For Motor Feedback
Only factory stocked part numbers are listed. Consult Factory for part number
and availability of other PPR and output configurations.
