3
When the desired output of a length sensor and wheel combination is either in feet or inch units, selection
of the proper combination is relatively straight forward. For example, with a 1-foot wheel circumference, a
1 PPR Rotary Pulse Generator will deliver 1 pulse/ft, 12 PPR would deliver 12 pulses/ft (1 pulse/inch); 100
PPR would yield 100 pulses/ft; and 120 PPR would permit measuring to 1/10th of an inch (1/120th of a foot).
SELECTING APPROPRIATE WHEEL SIZE & PPR (Pulses Per Rev.) OF ROTARY PULSE GENERATOR
LENGTH SENSOR ACCESSORIES
SEPARATE LENGTH MEASURING WHEELS - DIMENSIONS In Inches (mm)
Cast
Alum.
.376"
(9.6)
Bore
+.001"
-.000"
8-32 UNF
Set Screw
3/8"
(9.5)
Round Section Replaceable
Tire .210" Section Dia.
Black Neoprene
Diamond Knurled Aluminum
Tread
10-32 UNF
Set Screw
1"
(25.4)
Alum.
Cast
.376"
-.000"
+.001"
(9.6)
Bore
.376"
(9.6)
Bore
+.001"
-.000"
Tan, Smooth Polyurethane
Tread
10-32 UNF
Set Screw
Alum.
Cast
1"
(25.4)
OF
WHEEL
CODE
OK
WHEEL
CODE
FOR USE ON: Metal, paper,
foil, film and hard plastics.
Line contact on material
being measured,
convenient when available
measuring track is narrow
or for measuring on end of
roller beside passing
material.
Max. Speed: 600 RPM
FOR USE ON: Soft, smooth
materials such as soft
paper, matting, cardboard,
fine weave textiles. Broad
wheel tread minimizes
contact pressure and tan
polyurethane tread
minimizes marking.
Max. Speed: 600 RPM
Balanced version of 1ft.
circumference available.
Balanced to ANSI S2.19-
1989 Quality Grade 6.3 @
3000 RPM.
FOR USE ON: Rubber,
coarse weave fabrics,
rough wood surfaces,
foam, insulation.
Max. Speed: 600 RPM
Balanced version of 1ft.
circumference available.
Balanced to ANSI S2.19-
1989 Quality Grade 6.3
@ 3000 RPM.
OR
WHEEL
CODE
Note: After installation of measuring wheels, ensure guards,shields or other
devices are in place to protect personnel from rotating equipment.
WHEEL CODE CIRCUMFERENCE TOLERANCE PART NUMBER
1 foot (1/3 yd) ±0.35% WF1000OK
OK
1/3 meter ±0.30% WM0333OK
4/10ths yard ±0.30% WY0400OK
4/10ths meter ±0.30% WM0400OK
BK (Balanced) 1 foot (1/3 yd) ±0.35% WF1000BK
Replacement Tires
for OR Wheels
1 foot (1/3 yd) TORF1000
1/3 meter TORM0333
4/10ths yard TORY0400
4/10ths meter TORM0400
TOLERANCE WHEEL CODE CIRCUMFERENCE PART NUMBER
1 foot (1/3 yd) ±0.40% WF1000OR
OR
1/3 meter ±0.40% WM0333OR
4/10ths yard ±0.40% WY0400OR
4/10ths meter ±0.40% WM0400OR
1 foot (1/3 yd) ±0.35% WF1000OF
OF
1/3 meter ±0.30% WM0333OF
4/10ths yard ±0.30% WY0400OF
4/10ths meter ±0.30% WM0400OF
BF (Balanced) 1 foot (1/3 yd) ±0.40% WF1000BF
WHEELS & REPLACEMENT TIRES FOR CODE OR WHEELS
ORDERING INFORMATION
INSTALLATION:
1. Slide ZMH over a fixed Ш5/8" (Ш0.625 +0/-0.005") shaft. The optional ZMH
Mounting Bracket (MBZM0001) is shown in the picture.
2. While rotating the ZMH clamp to apply a spring load, securely tighten the two
clamp bolts with a 5/32" (supplied) or 4 mm hex “L” key.
Note 1: A 1/2 – 20 bolt can be threaded into the end of the clamp to aid in
loading the spring as shown. If a 1/2 – 20 bolt is not handy, then a Ø0.45"or
smaller rod, bolt, screw driver etc. works as well.
Note 2: The spring should not be preloaded too much or it may come in
contact with the spring limit pins and the ZMH will not have sufficient
travel to accommodate variations in the surface height of the material
being measured. For most applications, the spring setting in its mid-range
(5-6 lbs.) is sufficient.
ZMH INSTALLATION
