Red Lion C48T - Manual (Page 3)

3
Timer Range Modes -
UUSS""OO((&&
The timer can be configured to operate in one of 12 time ranges. The table
below shows the various ranges available with the time resolution of each
range.
MODE RANGE RESOLUTION
4&$
999.999 Seconds 0.001 sec
4&$
9999.99 Seconds 0.01 sec
4&$
99999.9 Seconds 0.1 sec
4&$
999999 Seconds 1 sec
O
999.999 Minutes 0.001 min
O
9999.99 Minutes 0.01 min
O
99999.9 Minutes 0.1 min
O4&$
9999.59 Minutes.Seconds 1 sec
O4&$
999.59.0 Minutes.Seconds.0 0.1 sec
IO4&$
99.59.59 Hours.Minutes.Seconds 1 sec
IO
99.59.99 Hours.Minutes.00 0.01 min
IO
999.59.9 Hours.Minutes.0 0.1 min
FRONT PANEL FEATURES
The C48 Timer features a dual line display. In
the normal operating mode (main display), the
timer value is shown on the top line and preset or
output time values are shown on the bottom line.
The Presets or Output time values can be
programmed to be viewable only, viewable and
changeable, or locked (not viewable) from the
main display.
In the normal operating mode, the presets and
output time values are accessible providing that
these values are not programmed for ‘L’ocked.
Values that are accessible (changeable) can be
changed immediately when viewed in the
secondary display.
USER INTERFACE/PROGRAMMING MODES
The operating modes of the C48T are programmed using the front panel
keypad. To enter the programming menu, the key is pushed and held for 2
seconds. Within the programming menu, the key is used to sequence through
the list of programming parameters.
PROGRAMMING MENU
DISPLAY
&OUS:
US"O&
-
-
PARAMETER DESCRIPTION
Digit or Auto Scrolling Data Entry Mode
Timer Range Modes (See Table on following page)
01&S
- Timer Operating Modes (See Table on following page)
S4U1V1
- Reset at Power up
"D 1S4
- Accessibility of Preset Values
1S&4&U
- Preset 1 and 2 Values
1US"D
- P1 Track P2 (C48TD only)
"D 0VU
- Accessibility of Output Time Values
0VUS&4
- Output Resolution
0VU1VU
- Output 1 and 2 Time Values
S&70VU
- Reverse Output/Relay Logic
S&7"OV
- Reverse Output Annunciator Logic
0VU1V1
- Power up Output State
64S*O
- User Input 1
64S*O
- User Input 2
64S*O
- User Input 3
64S '
- User F1 Key
$PE&
- Programming/Protected Parameter Menu Code
4DSP--
- Scroll Display
4&S4&U
- Serial Baud Rate and Parity Settings
4&S"ES
- Serial Unit Address
4&S"CS
- Abbreviate Serial Mnemonics
1SO01U
- Print Options
1SOS4U
- Print and Reset Time Value
'"D4&U
- Load Factory Default Settings
(RS485 option only)
FRONT PANEL KEYPAD
- Performs user Programmed Function
- Cycles through secondary displays.
- Enters Programming Mode or Protected Value Menu
when pushed and held for 2 seconds.
- Scrolls through programming displays.
- Enters Data Values.
- Selects next available mode in programming mode.
- Increments digit in Digit Entry mode.
- Increments value in Auto Scrolling entry mode.
- Selects Data Entry mode for displayed data values.
- Selects Digit to right when in Digit Entry mode.
- Decrements value in Auto Scrolling entry mode.
Program Security/Operator Accessible Values
The Program Disable Plug Jumper, Programmable Code Value, User
Input (programmed for Program Disable), and the Accessible value
parameter settings provide various levels of security against unauthorized
programming changes. The accessible value parameters provide individual
access or locking of each value.
Protected Value Menu
The Protected Value Menu allows access to selected presets and timed
output values without having them viewable or changeable from the main
display. To enter the protected menu, the
key is pressed and held, and a
programmed code value is entered.
