1. DISPLAY: 5 digit LCD 0.48" (12.2 mm) high digits
CUB5PR00: Reflective LCD with full viewing angle
CUB5PB00: Transmissive LCD with selectable red or green LED backlight,
viewing angle optimized. Display color change capability with output state
when using an output module.
2. POWER: Input voltage range is +9 to +28 VDC with short circuit and input
polarity protection. Must use an RLC model MLPS or an NEC Class 2 or
Limited Power Source (LPS) rated power supply.
3. INPUT RANGES: Jumper Selectable
0 to 10 V, 0(4) to 20 mA, 0 to 50 mA
4. SENSOR INPUTS:
5. OVERRANGE RATINGS, PROTECTION & INDICATION:
9 to 28 VDC power circuit is not isolated from the signal circuit.
Input Overrange Indication: “
OLOL ”.
Input Underrange Indication: “ ULUL ”.
Display Overrange/Underrange Indication: “ ..... ”/“- ..... ”
6. RESPONSE TIME:
Display: 500 msec min.
Output: 800 msec max (with input filter setting of 0)
7. NORMAL MODE REJECTION: 60 dB 50/60 Hz
8. USER INPUT (USR): Programmable input. Connect USR terminal to USR
COMM to activate function. Internal 10K
 pull-up resistor to +9 to 28 VDC.
Threshold Levels: V
IL
= 0.7 V max; V
IH
= 2.4 V min; V
MAX
= 28 VDC
Response Time: 5 msec typ.; 50 msec debounce (activation and release)
9. CONNECTIONS: Wire clamping screw terminals
Wire Strip Length: 0.3" (7.5 mm)
Wire Gage: 30-14 AWG copper wire
Torque: 5 inch-lbs (0.565 N-m) max.
10. MEMORY: Nonvolatile E 2 PROM memory retains all programming
parameters and max/min values when power is removed.
11. ENVIRONMENTAL CONDITIONS:
Operating Temperature Range for CUB5PR00: -35 to 75 °C
Operating Temperature Range for CUB5PB00 depends on display color
and intensity level as per below:
INTENSITY LEVEL TEMPERATURE
Red Display 1 & 2 -35 to 75 °C
3 -35 to 70 °C
4 -35 to 60 °C
5 -35 to 50 °C
Green Display 1 & 2 -35 to 75 °C
3 -35 to 65 °C
4 -35 to 50 °C
5 -35 to 35 °C
Storage Temperature: -35 to 85 °C
Operating and Storage Humidity: 0 to 85% max. relative humidity (non-
condensing)
Vibration to IEC 68-2-6: Operational 5-500 Hz, 5 g
Shock to IEC 68-2-27: Operational 30 g
Altitude: Up to 2000 meters
12. CERTIFICATIONS AND COMPLIANCES:
CE Approved
EN 61326-1 Immunity to Industrial Locations
Emission EN 55011 Class A
IEC/EN 61010-1
UL Recognized Component: File #E179259
UL Listed: File #E137808
Type 4X Enclosure rating (Face only)
IP65 Enclosure rating (Face only)
IP20 Enclosure rating (Rear of unit)
Refer to EMC Installation Guidelines section of the bulletin for additional
information.
13. CONSTRUCTION: This unit is rated for NEMA 4X/IP65 requirements for
outdoor use. Installation Category I, Pollution Degree 2. High impact plastic
case with clear viewing window. Panel gasket and mounting clip included.
14. WEIGHT: 3.2 oz (100 g)
2
G
ENERAL
M
ETER
S
PECIFICATIONS
O
RDERING
I
NFORMATION
MODEL
NO.
DISPLAY COLOR
INPUT CURRENT
@ 9 VDC WITH
CUB5RLY0
CUB5PR00 --- 10 mA 40 mA
CUB5PB00 Red (max intensity) 85 mA 115 mA
CUB5PB00 Green (max intensity) 95 mA 125 mA
INPUT CURRENT
@ 9 VDC WITHOUT
CUB5RLY0
ACCURACY
@23 °C, less
than 85% RH
INPUT
RANGE
INPUT
IMPEDANCE
MAX INPUT
SIGNAL
RESOLUTION
TEMP.
COEFFICIENT
20 / 50 mA 0.1% of span 10  150 mA 1 μA 70 ppm / °C
10 VDC 0.1% of span 538 K  30 V 1 mV 70 ppm / °C
TYPE MODEL NO. DESCRIPTION PART NUMBER
CUB5 CUB5P
Process Meter with Reflective Display CUB5PR00
Process Meter with Backlight Display CUB5PB00
Optional Plug-in Cards
CUB5RLY Single Relay Option Card CUB5RLY0
CUB5SNK Dual Sinking Open Collector Output Card CUB5SNK0
CUB5COM
RS485 Serial Communications Card CUB5COM1
RS232 Serial Communications Card CUB5COM2
CUB5USB USB Programming Card CUB5USB0
Accessories
MLPS
+12 VDC Micro-Line Power Supply, 85 to 250 VAC source, 400 mA max out MLPS1000
+24 VDC Micro-Line Power Supply, 85 to 250 VAC source, 200 mA max out MLPS2000
CBLPROG Programming Cable RS232 (RJ11-DB9) CBLPROG0
CBPRO Programming Cable RS485 (RJ11-DB9) CBPRO007
SFCRD Crimson PC Configuration Software, Free Download Available 1 SFCRD200
CBLUSB USB Programming Cable CBLUSB00
1 Crimson software is a free download from http://www.redlion.net. System requirements for the software are listed on the download page.
