2
O
rdering
i
nfOrmatiOn
Accessories Part Numbers
TYPE DESCRIPTION PART NUMBER USED WITH
Plug-in
Terminal Block
3 Position Terminal Block TB100003 CUB7CCS0, CUB7TCS0, CUB7TCS1
4 Position Terminal Block TB100004
CUB7CCG0, CUB7TCG0, CUB7TCG1,
CUB7CCR0, CUB7TCR0, CUB7TCR1,
CUB7CVS0, CUB7TVS0
5 Position Terminal Block TB100005
CUB7CVG0, CUB7TVG0, CUB7CVR0,
CUB7TVR0
Enclosure * CUB7 Enclosure ENC13000
Base Mount * CUB7 Base Mount BMK80000
See Wiring the Meter section to determine the terminal block needed.
* Enclosure and base mount will NOT function with plug-in terminal block option.
CUB7 0
C - LOW VOLTAGE
+28 VDC max
V - HIGH VOLTAGE
50-250 VAC/DC
S - REFLECTIVE
R - RED
G - GREEN
C
signals when using a VCM10000 converter module.
SRC mode (DIP switch 1 on, internal 20 kW pull-down to common)
V
IN
High Min = 1.25 VDC; V
IN
Low Max = 0.45 VDC
I
IN
Max = 5 mA; V
IN
Max = 28 VDC
Models: CUB7TCS1, CUB7TCR1, CUB7TCG1 For these models, the
unit will time when the CUB7 input is high.
SNK mode (DIP switch 1 off - DO NOT USE)
SRC mode (DIP switch 1 on, internal 20 kW pull-down to common)
V
IN
High Min = 1.25 VDC; V
IN
Low Max = 0.45 VDC
I
IN
Max = 5 mA; V
IN
Max = 28 VDC
4. HIGH VOLTAGE INPUT:
COUNTERS: CUB7CVS0, CUB7CVR0, and CUB7CVG0
The unit adds one count with voltage present
V
IN
Range = 50-250 VDC/VAC 50/60 Hz, 5 mA max
Isolation: 2500 VAC 1 min
TIMERS: CUB7TVS0, CUB7TVR0, and CUB7TVG0
Unit will time with voltage present
V
IN
Range = 50-250 VDC/VAC 50/60 Hz, 5 mA max
Isolation: 2500 VAC 1 min
5. RESET INPUT:
V
IN
Low Max = 1.5 VDC (internal pull-up to battery)
I
IN
Max = 20 µA
5 msec min (active low)
Note: Reset input is active low to clear display to zero
6. TIMER ACCURACY:
CUB7TV: 0.03% +100 msec per RUN terminal activation
CUB7TC low freq/snk setup: 0.03% +1 msec per RUN terminal activation
CUB7TC high freq/snk setup: 0.03% -1 msec per RUN terminal activation
7. ENVIRONMENTAL CONDITIONS:
Operating Temperature: 0 to 50 °C
Storage Temperature: -30 to 80 °C
Vibration according to IEC 68-2-6: Operational 5 to 500 Hz, in X, Y, Z
direction for 1.5 hours, 5 g.
Shock according to IEC 68-2-27: Operational 30 g, 11 msec in 3 directions.
Operating and Storage Humidity: 85% max. (non-condensing)
8. CONNECTIONS: 22 gauge wire; wire length minimum 10"
OPTIONAL TERMINAL BLOCKS: Wire clamping terminals
Wire Strip Length: 0.275" (7 mm)
Wire Gage: 24-16 AWG copper wire
9. CONSTRUCTION: High impact plastic case with clear viewing window.
The front panel meets NEMA 4X/IP65 requirements for outdoor use when
properly installed. Installation Category II, Pollution Degree 2. Panel gasket
and mounting clip are included.
10. CERTIFICATIONS AND COMPLIANCES:
SAFETY
UL Listed, File # E179259, UL508
Type 4X Outdoor Enclosure rating (Face only), UL50
IEC 61010-1, EN 61010-1: Safety requirements for electrical equipment
for measurement, control, and laboratory use, Part 1.
IP65 Enclosure rating (Face only), IEC 529
ELECTROMAGNETIC COMPATIBILITY
Emissions and Immunity to EN 61326:2006: Electrical Equipment for
Measurement, Control and Laboratory use.
Immunity to Industrial Locations:
Electrostatic discharge EN 61000-4-2 Criterion A
4 kV contact discharge
8 kV air discharge
Electromagnetic RF fields EN 61000-4-3 Criterion A
10 V/m (80 MHz to 1 GHz)
3 V/m (1.4 GHz to 2 GHz)
1 V/m (2 GHz to 2.7 GHz)
Fast transients (burst) EN 61000-4-4 Criterion A
2 kV power
1 kV I/O signal
Surge EN 61000-4-5 Criterion A
power 1 kV L to L,
2 kV L to G
RF conducted interference EN 61000-4-6 Criterion A
3 Vrms
Power freq magnetic fields EN 61000-4-8 Criterion A
30 A/m
AC power EN 61000-4-11
Voltage dip Criterion A
0% during 1 cycle
40% during 10/12 cycle
70% during 25/30 cycle
Short interruptions Criterion B
0% during 250/300 cycles
Emissions:
Emissions EN 55011 Class B
Notes:
1. Criterion A: Normal operation within specified limits.
2. Criterion B: Temporary loss of performance from which the unit self-
recovers.
Refer to the EMC Installation Guidelines section of the bulletin for
additional information.
11. WEIGHT: 0.11 lbs. (0.05 Kg)
COUNTERS
CUB7 0
C - LOW VOLTAGE
+28 VDC max
V - HIGH VOLTAGE
50-250 VAC/DC
S - REFLECTIVE
R - RED
G - GREEN
T
0 - USE WITH LOW VOLTAGE TO
TIME WHEN INPUT IS LOW
USE WITH HIGH VOLTAGE TO
TIME WHEN INPUT IS HIGH
1 - VALID ONLY WITH LOW VOLTAGE (C)
USE WITH 28 VDC (SRC MODE) TO
TIME WHEN INPUT IS HIGH
TIMERS
