2

PROGRAMMABLE FUNCTIONS

UNIT PERSONALITY

Functions as a Counter and Rate Indicator.

PRESET(S)

Range 0 to ±999999

SCALE FACTORS

5-digit input scaling, Range 0.0000 to ±5.9999.

SCALE MULTIPLIER

Multiplies the contents of the 9-digit internal counter by a factor of 1, 0.1, 0.01,

or 0.001 to view the desired number of significant digits on the 6-digit display.

COUNTING MODES

Count with Inhibit
Count with Up/Down Control
2-Input Anti-Coincidence Add
2-Input Anti-Coincidence Add/Subtract
Quadrature
Quadrature X4

RESET ACTION
Reset-to-Zero:
Output activates when count equals the preset value. Counter

returns to zero when reset.

Reset-to-Preset: Output activates when count equals zero. Counter returns to

preset value when reset.

RESET MODES

Manual Reset
Automatic Reset at Preset
Automatic Reset after Output Time Delay

Note: Manual reset via front panel pushbutton or remote “RST.” terminal can

be programmed for momentary or maintained action. Front panel reset may
be disabled by a switch at the rear of the unit.

SELF-TEST

Performs a complete check on the display and output circuitry along with a

functional check on the CPU. Self-test is non-destructive and may be
performed during a process without losing counts.

FREQUENCY DOUBLING

Registers counts on both edges of input signal.

DECIMAL POINT & LEADING ZERO BLANKING

Decimal point programmable to desired location. Leading zero blanking,

when selected, begins with second digit to the left of the decimal point.

RIGHT-HAND DUMMY ZEROS

Up to three non-functional zeros may be placed on the least significant end

of the display.

OUTPUT TERMINATION MODES

Terminate at “other” Output Start (Gemini 2000 only)
Terminate at “other” Output End (Gemini 2000 only)
Terminate at Manual Reset
Terminate at Manual Reset End
Terminate after Time Delay
Boundary

For positive preset value: Output terminates when Display is less than

Preset.

For negative preset value: Output terminates when Display is greater than

Preset (i.e. more positive).

Note: In any of the above modes, the unit may be programmed for “Reverse

Phase” operation which complements the logic state of the output.

OUTPUT TIME DELAY

Programmable from 0.01 to 599.99 seconds. Accurate to ±(0.01% + 10 msec.).

SAMPLE TIME MULTIPLIER

Multiplies the basic one-second data sampling time by 1, 2, 5, 10,
20, or 50. Accurate to ±0.01%.

FRONT PANEL LOCKOUT MODES

When the “Program Disable” control input is activated, the ability to change

front panel programmed functions will be prevented as per the following modes:

Complete Front Panel Disable
Preset(s) Enabled Only
Scale Factor Enabled Only
Both Preset(s) and Scale Factor Enabled

Note: Reset may be enabled or disabled in any of the above modes.

SPECIFICATIONS (Cont’d)

Lo Bias - Input trigger levels V

IL

= 1.5 V max., V

IH

= 3.75 V.

Hi Bias - Input trigger levels V

IL

= 5.5 V max., V

IH

= 7.5 V.

Note: Bias levels given are ±10% @ 12 VDC. They vary proportionally

with sensor supply voltage.

6. MAGNETIC PICKUP INPUT:

Sensitivity - 150 mV peak nominal
Hysteresis - 100 mV nominal
Input Impedance - 26.5 K

@ 60 Hz nominal

Maximum Input Voltage - ±50 V peak

7. MAXIMUM COUNT RATES:

Uni- or Bi-Directional Modes: 9 KHz; 8 KHz (X2)
2-Input Anti-Coincidence Modes: 5 KHz; 4 KHz (X2)
Quadrature Modes: 5 KHz; 4 KHz (X2 or X4)
Rate Indicator: 10 KHz; 8 KHz (X2)

8. CONTROL INPUTS:

Reset - Active Low (V

IL

= 1.5 V max.) internally pulled up to +12 VDC

(I

SNK

= 3 mA), response time = 10 msec (typical).

Program Disable - Active Low (V

IL

= 1.5 V max.), internally pulled up to

+5 VDC (I

SNK

= 1 mA).

Print Request - (GEM2 only) Active Low (V

IL

= 1.5 V max.) internally

pulled up to +5 VDC (I

SNK

= 1 mA).

9. SERIAL COMMUNICATIONS (Optional, Gemini 2000 only):

Type - Bi-directional 20 mA current loop, 20 mA source provided. (Powers

up to seven units in a loop with internal current source.)

Baud Rate - Programmable 300 to 2400.
Maximum Address - 16 units (0 to 15). (Actual number in a single loop is

limited by serial hardware specifications.)

Data Format - 10 bit frame, Odd parity (one start bit, 7 data bits, one odd

parity bit, and one stop bit.)

Serial Hardware Specifications -

SO - Output Transistor Rating: V

MAX

= 30 VDC, V

SAT

= 1 V

MAX

@ 20

mA. (Can address 16 units in a loop)

SI - Input Diode Rating: V

F

= 1.25 V

TYP

; 1.5 V

MAX

Note: The compliance voltage rating of the source must be greater than

the sum of the voltage drops around the loop.

10. OUTPUT(S):

Solid-State - Current sinking NPN Open Collector Transistor(s). I

SNK

= 100

mA max. V

OH

= 30 VDC max. (Internal Zener Diode Protected). V

OL

=

1 VDC max @ 100 mA

Relay(s) - Mounted on a field-replaceable P.C. board. Form C contacts rated

5 amps @ 120/240 VAC, 28 VDC (resistive load), 1/8 H.P. @ 120 VAC
(inductive load). The operate time is 5 msec nominal and the release time
is 3 msec nominal.

Relay Life Expectancy - 100,000 cycles at max. rating. (As load level

decreases, life expectancy increases.)

Programmable Timed Outputs(s) - The timed output(s) can be set from

0.01 to 599.99 seconds, ±(0.01% + 10 msec).

11. CERTIFICATIONS AND COMPLIANCES:

SAFETY

IEC 1010-1, EN 61010-1: Safety requirements for electrical equipment for

measurement, control, and laboratory use, Part 1.

IP65 Enclosure rating (Face only), IEC 529
Type 4 Enclosure rating (Face only), UL50

ELECTROMAGNETIC COMPATIBILITY:

Notes:
1. Metal bezel of unit connected with ground lead from rear bezel screw to

metal mounting panel.

2. When the unit is DC powered, a power line filter (RLC# LFIL0000 or

equivalent) was installed, so as not to impair the function of the unit.

Refer to the EMC Installation Guidelines section of the manual for

additional information.

Immunity to EN 50082-2
Electrostatic discharge

EN 61000-4-2

Level 2; 4 Kv contact

1

Level 3; 8 Kv air

Electromagnetic RF fields

EN 61000-4-3

Level 3; 10 V/m
80 MHz - 1 GHz

Fast transients (burst)

EN 61000-4-4

Level 4; 2 Kv I/O
2 Kv power

2

RF conducted interference

EN 61000-4-6

Level 3; 10 V/rms
150 KHz - 80 MHz

EN 61000-4-8

Level 4; 30 A/m

Emissions to EN 50081-2
RF interference

EN 55011

Enclosure class A
Power mains class A

Power frequency magnetic fields
