SPECIFICATIONS
1. POWER: Power will be supplied by the Graphite host device. Some
modules, depending on usage may consume high levels of power. This may
limit the total number of modules that can be installed on a single Graphite
host. Check the Graphite module and Graphite host data sheets for specific
usage and power requirements.
GMSG1 Max Power: 5.6 W
2. LEDs*:
STS - Status LED shows module condition.
OP1, OP2, OP3 - Indicate status of outputs 1, 2, and 3
ALM - Alarm LED is lit during any internal alarm condition.
* Default configuration.
3. MEMORY: Non-volatile memory retains all programmable parameters.
4. INPUTS:
SELECTABLE
INPUT RANGE
ACCURACY *
18 TO 28°C
10 TO 75% RH
ACCURACY *
0 TO 50°C
0 TO 85% RH
ACCURACY *
-40 TO 70°C
0 TO 85% RH
±20.000 mVDC 0.02% of reading
+3 µV
0.07% of reading
+4 µV
0.09% of reading
+5 µV
±33.000 mVDC 0.02% of reading
+5 µV
0.07% of reading
+7 µV
0.09% of reading
+9 µV
±200.00 mVDC 0.02% of reading
+30 µV
0.07% of reading
+40 µV
0.09% of reading
+50 µV
* After 20 minute warm-up. Accuracy includes the temperature coefficient.
Connection Type:
4-wire bridge (differential)
2-wire (single-ended)
Sample Time: 50 msec (20 readings per second)
Common Mode Range (with respect to input common): 0 to +5 VDC
Common Mode Rejection: > 100 dB, DC to 120 Hz
Temperature Coefficient (ratio metric): 20 ppm/°C max.
Step Response Time: 200 msec max. to within 99% of final process value
Input Impedance: 100 MΩ
Max Continuous Overload: 30 V
PV Range: -30,000 to 30,000
Effective Resolution: 16-bit
5. BRIDGE EXCITATIONS:
Software selectable:
5 VDC, ±2%, 65 mA max.
10 VDC, ±2%, 125 mA max. combined (excitation 1 plus excitation 2).
Temperature coefficient (ratio metric): 20 ppm/°C max.
Max. four 350Ω bridges per module.
6. ISOLATION LEVEL: 500 Vrms @ 50/60 Hz for 1 minute between the
following:
OP1 * OP2 * OP3 *
Linear Output
Signal Inputs (the 2 input channels are not isolated from each other)
Power Supply Input
* Outputs OP1, OP2 and OP3 of SSR model are not isolated from each other
7. COMMUNICATIONS: Provided by the Graphite host device.
8. DISCRETE OUTPUTS:
Available as (3) Solid State NFET, or (3) Form A relay.
Solid State Output:
Type: Switched DC, N Channel open drain MOSFET
Current Rating: 1 A max
VDS ON: 0.3 V @ 1 A
VDS MAX: 30 VDC
Offstate Leakage Current: 0.5 mA max
Form A Relay Output:
Type: N.O.
Current Rating: 3 Amps @ 125 VAC
1/10 HP @ 125 VAC
Life Expectancy: 200,000 cycles at maximum load rating. (Decreasing
load, increasing cycle time, and use of surge suppression such as RC
snubbers increases life expectancy.)
9. CONTROL MODES:
Control: On/Off, P, PI, or PID
Output: Time proportioning or linear
Cycle Time: Programmable from 0.0 to 60.0 sec
Auto-Tune: When selected, sets proportional band, integral time, derivative
time values, and output dampening time
Input Fault Response: Upscale
10. ALARMS:
Modes: Manual
Absolute High Acting Absolute Low Acting
Deviation High Acting Deviation Low Acting
Inside Band Acting Outside Band Acting
Reset Action: Programmable; automatic or latched
Standby Mode: Programmable; enable or disable
Hysteresis: Programmable
Input Fault Response: Upscale
11. ANALOG DC OUTPUT:
Software programmable for 0-10 VDC, 0-20 mA, or 4-20 mA
Resolution:
Voltage: 500 µV
Current: 1 µA
Accuracy:
0.1% of full scale (18 to 28°C)
0.2% of full scale (-40 to 70°C)
Update Time: 0.0 to 60.0 sec
Compliance (for current output only): 500 Ω max.
Minimum load (voltage output only): 10 KΩ min.
Output is software selectable for either 10 V or 20 mA. The output range may
be field calibrated to yield approximate 10% overrange and a small
underrange (negative) signal.
12. ENVIRONMENTAL CONDITIONS:
Operating Temperature Range: -40 to +70°C
Storage Temperature Range: -40 to +85°C
Operating and Storage Humidity: 85% max relative humidity, non-condensing,
from 0 to +50°C
Altitude: Up to 2000 meters
13. CERTIFICATIONS AND COMPLIANCES:
CE Approved
EN 61326-1 to Industrial Locations
IEC/EN 61010-1
RoHS Compliant
14. CONSTRUCTION: Case body is all metal construction. For indoor use
only. Installation Category II, Pollution Degree 2.
15. CONNECTIONS: Removable wire clamp screw terminal blocks.
Wire Gage: 28-16 AWG terminal gage wire
Torque: 6.0 lbf-inch (96 oz-inch)
16. MOUNTING: Screws to host.
17. WEIGHT: 8 oz (224 g)
