LEDS
STS – STATUS LED
The Status LED is a green LED that provides information regarding the state
of the module. This includes indication of the various stages of the start-up
routine (power-up), as well as any errors that may occur.
Startup Routine
Off
Module is currently running the boot loader and/or
being flash upgraded by Crimson.
Flashing Green Module switching to configuration.
Green Module performing normally.
Error States
Flashing Green
Module is controlling properly, but has lost
communication with the Host.
FIRMWARE UPGRADE
The module’s firmware is stored in flash memory so that software/hardware
conflicts are avoided, and so features can be added in the future.
During a download, Crimson compares its own library of firmware files with
those stored in the module. If they do not match, Crimson will download the
necessary firmware.
CONFIGURATION
Programming is done via Crimson, a Windows ® compatible configuration
interface. Please see the Crimson manual for more information.
5
ORDERING INFORMATION
TYPE DESCRIPTION PART NUMBER
Operator
Interface Panels
Graphite 7" Color Touch Screen, Indoor, 24 VDC Powered G07C0000
Graphite 7" Color Touch Screen, Indoor/Outdoor, 24 VDC Powered G07S0000
Graphite 9" Color Touch Screen, Indoor, 24 VDC Powered G09C0000
Graphite 9" Color Touch Screen, Indoor, 24 VDC Powered, Additional Ethernet Port G09C1000
Graphite 10" Color Touch Screen, Indoor, 24 VDC Powered G10C0000
Graphite 10" Color Touch Screen, Indoor, 24 VDC Powered, Additional Ethernet Port G10C1000
Graphite 10" High Resolution Display, Color Touch Screen, Indoor, 24 VDC Powered G10R0000
Graphite 10" High Resolution Display, Color Touch Screen, Indoor, 24 VDC Powered, Additional Ethernet Port G10R1000
Graphite 10" Color Touch Screen, Indoor/Outdoor, 24 VDC Powered G10S0000
Graphite 10" Color Touch Screen, Indoor/Outdoor, 24 VDC Powered, Additional Ethernet Port G10S1000
Graphite 12" Color Touch Screen, Indoor, 24 VDC Powered G12C0000
Graphite 12" Color Touch Screen, Indoor, 24 VDC Powered, Additional Ethernet And Serial Port G12C1100
Graphite 15" Color Touch Screen, Indoor, 24 VDC Powered G15C0000
Graphite 15" Color Touch Screen, Indoor, 24 VDC Powered, Additional Ethernet And Serial Port G15C1100
Input Modules
Graphite Module, Digital I/O, 8 Inputs And 6 Relays Outputs GMDIOR00
Graphite Module, Digital I/O, 8 Inputs And 6 Solid State Outputs GMDIOS00
