0601-019 Figure 12 Mounting WMT52 to Pole Mast Using Optional
Mounting Kit
Mounting To Horizontal Cross Arm
1. Remove the screw cover.
2. Align the horizontal cross arm in south-north-direction, see
Aligning the WMT52 on page 36 . In case the cross arm cannot be
aligned, make the wind direction offset as instructed in section
Wind Direction Offset on page 37 .
3. Mount the sensor into the cross arm by using a mounting bolt
(M6 DIN933) and a nut, see
Figure 13 on page 33 and Figure 14 on
page 33 .
The following numbers refer to Figure 12 on page 32 :
1 = Fixing screw
2 = Mounting kit
NOTE When removing the WMT52 from the pole just turn the sensor so that
it snaps out from the mounting kit. When replacing the device the
alignment is not needed.
