USER'S GUIDE____________________________________________________________________
14 __________________________________________________________________ M211289EN-A
NPT Adapter (Optional)
The DMT132 can be connected to NPT 1/2" threaded mounting points
using the optional NPT adapter (Vaisala order code 210662).
1101-061
Figure 5
DMT132 with NPT Adapter
NOTE
When the NPT adapter is used, the filter is partially covered by the
adapter; see Figure 5 above. This doubles the response time of the
transmitter. The adapter is suitable for use in compressed air lines and
other systems with sufficient flow.
