Chapter 7 _____________________________________________________________ Technical Data
VAISALA ________________________________________________________________________ 81
Table 13 Mechanical Specifications
Property Description / Value
Material
Transmitter housing PBT plastic
Display window PC plastic
Probe body Stainless steel (AISI 316)
Probe grid filter Chrome coated ABS plastic
Housing classification IP65 (NEMA 4)
Connections
Voltage outputs and RS-485 Screw terminals 0.5 ... 1.5 mm²
Probe interface 4-pin M8 female panel connector
Probe cable lengths 3 m, 5 m, 10 m, 20 m cables
can be cascaded up to 50 m
Display (optional) 128x64 resolution full graphics
B&W display without backlight
Weight (Wall model, including probe)
Weight (10m cable model)
270 g
540 g
Options and Accessories
Table 14 Options and Accessories
Description Order Code
HMP110 probe for HMT130 HMP110 – separate order form
HMP110R replacement probe for
HMT130
HMP110R – separate order form
HMP110T temperature only probe
for HMT130
HMP110T – separate order form
Constant output probe HMP110REF – separate order form
Humidity sensor Humicap180R
Probe mounting flange 226061
Probe mounting clamp, 1 piece 225501
Probe mounting clamp set, 10 pcs 226067
Sensor protection
Plastic grid filter DRW010522SP
Membrane filter DRW010525
Stainless steel sintered filter HM46670SP
Probe cable 3 m HMT120Z300
Probe cable 5 m HMT120Z500
Probe cable 10 m HMT120Z1000
Probe cable 20 m HMT120Z2000
Radiation shield DTR504A
Probe installation kit for DTR504 227777
Rain shield with installation kit 215109
Duct installation kit 215619
HMI41 connection cable 25917ZZ
HM70 connection cable 211339
Service cable for PC, USB 219685
