Sandvik Coromant Silent tools - application guide - Manual (Page 7)

5
1. Introduction
The dampening system consists of a heavy
mass, supported on rubber spring elements.
Rubber springs
Dampening system
inside tool body
• Heavy metal body
• Pre-tuned
• High reliability
Oil is added to increase the dampening
It is important to respect the limits marked on the product (load,
temperature, rotation, min/ max overhang and pressure):
• Temperature is highlighted to save the rubber elements in the
dampening system
• Maximum temperature limit depends on type of product and is
marked on the tool, eg. 75-120°C (167-248 F)
