61
3. Turning
Two lines on the bar indicate minimum and
maximum overhang. Make sure that the
overhang is within that range. Outside this
range, there is no guarantee for the damp-
ening function.
Modification of standard bars
Bar diameter
L, min length after cut off
BD
Short design
4–7 × BD
Long design
7–10 × BD
mm
mm
mm
16
100
155
20
125
200
25
155
255
32
190
320
40
240
410
50
305
520
60
380
630
80
630
630
100
770
770
We recommend a min. clamping length of 4 × BD
Bar diameter
L, min length after cut off
BD
Short design
4–7 × BD
Long design
7–10 × BD
inch
inch
inch
0.625
4
7
0.750
5
8
1.000
7
11
1.250
8
13
1.500
10
17
1.750
10.4
18
2.000
12
21
2.500
15
25
3
20
20
4
30.3
30.3
We recommend a minimum clamping length of 4 × BD
