Backup Power Supply Pinouts
OmniSwitch 6800 Series Chassis and Hardware Components
page 2-52
OmniSwitch 6800 Series Hardware Users Guide
June 2007
Backup Power Supply Pinouts
OS6800-BPS-225 225W Backup Power Supply Connector
OS6800-BPS-225 225W Backup Power Supply Cable
Pin Number
1
-50 VDC
2
Ground
3
Enable
4
RPS_ABNORMAL
5
NC
Pin Number
Power Shelf Side
Pin Number
Switch Side
2
Ground
1
-48 RTN
2
NC
3
Enable
3
Enable
2
Ground
4
-48 RTN
5
SYSPWRFAIL_L
1
-50 VDC
6
-48 DC
4
RPS_ABNORMAL
7
RPS_ABNORMAL
1
Ground
8
-48 DC
2
Enable
9
-48 RTN
RPS_ABNORMAL
10
NC
2
NC
11
-48 RTN
-50 VDC
12
Ground (Secondary)
Ground
13
NC
1
Enable
14
-48 VDC
RPS_ABNORMAL
15
NC
1
NC
16
-48 VDC
