Status LEDs OmniSwitch 6800 Series Chassis and Hardware Components
page 2-14 OmniSwitch 6800 Series Hardware Users Guide June 2007
10/100/1000 LEDs
There are two LEDS on 10/100/1000 ports. The left-hand LED is the data speed LED. Displays solid
green for 1000 Mbps; displays amber for 100 Mbps; off for 10 Mbps or no traffic flow. The right-hand
LED is the link/activity status LED. Displays solid green when a link state exists; blinks green to show
activity (transmitting or receiving traffic); off when no activity is present.
1000 SFP LEDs
There is a single LED for 1000 Mbps SFP connectors. Displays solid green for a valid link; blinks green
when transmitting or receiving packets in a link up state; off when no link is detected.
10/100 LEDs
There are two LEDS on 10/100 ports. The left-hand LED is the data speed LED. Displays solid green for
100 Mbps; displays amber for 10 Mbps; off for no traffic flow. The right-hand LED is the link/activity
status LED. Displays solid green when a link state exists; blinks green to show activity (transmitting or
receiving traffic); off when no activity is present.
