OmniSwitch 6800 Series OmniSwitch 6800 Series Application Examples
OmniSwitch 6800 Series Hardware Users Guide June 2007 page 1-11
Small Enterprise Core
With its high-speed switching capacity, supported Layer 3 routing protocols, advanced network services,
and wire speed 10 Gigabit capability, the OmniSwitch 6800 Series provides effective core switching for
smaller Enterprise networks (200-500 ports). For example:
Application Example: Small Enterprise Core
10/100 layer 2 Switching
Servers
Gigabit Layer 3 Switching
Internet
Internet
Router
Gigabit Uplinks
OmniSwitch 6800
Series Switch OmniSwitch 6800
Series Switch
10/100 layer 2 Switching
10/100 layer 2 Switching
