OS6800-XNI-U2 10 Gigabit Expansion Module
OmniSwitch 6800 Series Chassis and Hardware Components
page 2-36
OmniSwitch 6800 Series Hardware Users Guide
June 2007
10 GigE Interoperability Between OS6800 and OS8800 Switches
In order to have 10 Gigabit uplink operability between OS6800 and OS8800 switches, users must issue the
bridge port 10gig os8800optimized
command on the OS6800 switch. The command must be issued sepa-
rately for each 10 Gigabit port. The following examples show operability being enabled on both
10 Gigabit ports installed in an OS6800-U24 chassis:
-> bridge port 1/25 10gig os8800optimized enable
-> bridge port 1/26 10gig os8800optimized enable
For more information on specifying 10 Gigabit slot and port numbers, refer to
Note. The bridge port 10gig os8800optimized command applies only to OS6800-48, OS6800-48L, and
OS6800-U24 switches being connected to OS8800 switches via a 10 Gigabit uplink. For more informa-
tion on this command, refer to the CLI Reference Guide.
Viewing Interoperability Status
To view whether a 10 Gigabit port has been optimized for use with OS8800 switches, use the
show spantree ports
command. Be sure to include the keyword configured in the command line.
For example:
-> show spantree 1 ports configured
Spanning Tree Port Admin Configuration for Vlan 1
Port Adm Man. Config Adm OS8800
Port Pri St. Mode Cost Cnx 10G Opt.
-----+----+----+----+-------+----+--------
1/1 7 ENA No 0 AUT DIS
1/2 7 ENA No 0 AUT DIS
1/3 7 ENA No 0 AUT DIS
1/4 7 ENA No 0 AUT DIS
1/5 7 ENA No 0 AUT DIS
1/6 7 ENA No 0 AUT DIS
1/7 7 ENA No 0 AUT DIS
1/8 7 ENA No 0 AUT DIS
1/9 7 ENA No 0 AUT DIS
1/10 7 ENA No 0 AUT DIS
1/11 7 ENA No 0 AUT DIS
1/12 7 ENA No 0 AUT DIS
1/13 7 ENA No 0 AUT DIS
1/14 7 ENA No 0 AUT DIS
1/15 7 ENA No 0 AUT DIS
1/16 7 ENA No 0 AUT DIS
1/17 7 ENA No 0 AUT DIS
1/18 7 ENA No 0 AUT DIS
1/19 7 ENA No 0 AUT DIS
1/20 7 ENA No 0 AUT DIS
1/21 7 ENA No 0 AUT DIS
1/22 7 ENA No 0 AUT DIS
1/23 7 ENA No 0 AUT DIS
1/24 7 ENA No 0 AUT DIS
1/25 7 ENA No 0 AUT ENA
1/26 7 ENA No 0 AUT ENA
10 Gigabit/OS8800 optimization is
shown enabled on both 10 Gigabit ports in
the chassis (an OS6800-U24 in this case).
