GReddy TURBO KITS: Acura RSX Type-S 2002-03 / T517Z User Manual
Page 20
e-manage Factory
ECU
Pin
#
Wire Color Description ECU Pin # Color
Code
3
White
MAP IN
A19
(harness)
Green/Red
MAP
4
Grey
Throttle A15
Red/Black
TPS
5
Blue/Red
INJ 1
B5
Brown
INJ 1
6
Orange/Red
INJ 2
B4
Red
INJ 2
7
Yellow/Red
INJ 3
B3
Blue
INJ 3
8
Purple/Red
INJ 4
B2
Yellow
INJ 4
10
Green
MAP
OUT
A19
(ECU side)
Green/Red
MAP
11
Brown
RPM E26
Blue
NEP
12
Black
GND A5
Black
PG1
13
Red
+B A3
Yellow/Black
IGP1
18
Black/Red
INJ GND A5
Black
PG1
e-manage Factory
ECU
Pin # Wire Color Description
ECU Pin #
Color
Code
3
Purple/White
IGT4 IN
A27
(ECU side)
Brown
IGPLS4
4
Orange/White
IGT2 IN
A29
(ECU side)
Blue/Red
IGPLS2
5
Blue/White
IGT1 IN
A30
(ECU side)
Yellow/Green
IGPLS1
8
Purple/Black
IGT4
OUT
A27
(Harness)
Brown
IGPLS4
9
Yellow/Black
IGT3
OUT
A28
(Harness)
White/Blue
IGPLS3
10
Yellow/White
IGT3 IN
A28
(ECU side)
White/Blue
IGPLS3
11
Orange/Black
IGT2
OUT
A29
(Harness)
Blue/Red
IGPLS2
12
Blue/Black
IGT1
OUT
A30
(Harness)
Yellow/Green
IGPLS1
* Looking at harness side.
I/J Harness (18Pin)
* Looking at harness side.
IG Harness (12Pin)
Sensor Adapter
Factory ECU
Wire Color
Description
ECU Pin #
Color
Code
White (male)
KNK IN
A9
(Harness)
Red/Blue
KS
Green (female)
KNK OUT
A9
(ECU side)
Red/Blue
KS
Black KNK
GND
A10
Green/Yellow
SG2
Important !
Make sure the all the wire connections are correct. If they are connected
incorrectly, it can damage the e-Manage, ignition coils, and/or ECU.
(5) Reinstall the ECU back in its place, and secure the e-Manage next to the ECU.
* Avoid mounting the e-Manage unit in the area that would be exposed to direct
sun light, moisture, or near heater outlet
