DAVIS Vantage Pro2 Console - Manual (Page 26)

Selecting Units of Measure
23
Solar Radiation
Press and release 2ND then press SOLAR to display the current
solar radiation reading. Solar radiation is displayed as Watts per
square meter (W/m
2
).
Current Evapotranspiration (ET)
Press and release 2ND then press ET to display the current evapo-
transpiration reading.
Monthly Evapotranspiration (ET)
Press 2ND then press ET, then repeat the key sequence to display Monthly ET.
Yearly Evapotranspiration (ET)
Press 2ND then press ET, then repeat this key sequence two more times to display the
ET reading since January 1st of the current year.
Note: A solar radiation sensor is required to take readings listed above. See “Optional Sen-
sors & Transmitting Stations” on page 2.
Lamps
Press 2ND then press LAMPS to turn on the backlight for the screen display.
Press 2ND then LAMPS again to turn the backlight off.
Use the backlight when the LCD is not clearly visible. When the console is
battery operated, the backlight remains on as long as keys are pressed or a ticker tape
message is scrolling across the screen. If no keys are pressed, the backlight automati-
cally turns off about fifteen seconds after it is turned on. If any key is pressed while it is
turned on, it will stay illuminated for 60 seconds from the last key press. When battery
power is low, the backlight does not light.
Note: When the console receives power from the AC adapter, the backlight remains on
until it is toggled off. Leaving the backlight on raises the inside temperature reading
and lowers the inside humidity reading.
N
W
NE
SE SW
GRAPH
Vertical Scale: X10
WIND
RAIN YEAR
in
TEMP OUT
HUM IN
YEAR
HUM OUT
DAILY RAIN
in
TEMP IN
hPa
BAROMETER
STATION NO.1
F
F
F
MPH
Last 24 hrs hr Every 1
S
E
NW
pm
HEAT INDEX
ET
mm
ET
MO
mm
ET
YEAR
mm
SUN
W/m 2
Solar Radiation, Current ET, ET Month & ET Year
RAIN
DAY
SOLAR
2 ND
BAR
ET
2 ND
2
LAMPS
ND
