Install the Rain Collector
4
houses, fences -- and as low as possible out of the wind.
To install the rain collector on a sheet metal roof, insulate the unit by making a platform
out of wood. Mount the base of the rain collector at least 1" (4
cm) away from any steel
or iron surface and make sure the reed switch is at least 1" (4 cm) away from any steel or
iron objects (e.g., nails).
•Choose a location which is easily accessible for normal cleaning and is distant from
trees or other sources of heavy pollen or debris.
Installing the Rain Collector
The following instructions assume the rain collector is being used with a Vantage
Pro2 or Vantage Pro2 Plus ISS. Refer to the user manual that came with your station
for more information.
Tip: Manuals are available online at www.davisnet.com in the Weather Support section.
1. If you have not already done so, separate the cone from the base and disconnect
the rain collector cable from the sensor interface in the transmitter shelter.
2. Place the base on the mounting surface and mark the location of the four holes
(the base has eight to choose from) you will use to secure the base.
3. Make pilot holes using a 3/32" (2 mm) drill bit. You should make the pilot holes
about 1/2" (12 mm) deep.
4. Fasten the base to the mounting
surface using the #8 x 3/4” screws
provided.
