Page 3
3
Mounting the Solar Power Kit With Vantage Pro2
Stations
Most people mount the Solar Power Kit on the galvanized steel tube in the
Mounting Pole Kit (#7717) or Mounting Tripod (#7716) that is used to mount
the weather station. For tripod installation, refer to your tripod manual (if nec-
essary). The following are examples of different Solar Power Kit assemblies,
one on a tripod, another mounted to a fence or post, using the Vantage Pro2
console and Envoy.
Vantage Pro2
ISS
Anemometer
Facing NORTH*
Weather Envoy
or Envoy8X
Multi-Purpose
Shelter
or
Complete System
Shelter
Solar Panel
Facing SOUTH*
Brace
Clamp
Solar Panel
Shelter
Optional
Mounting
Tripod
*In the Northern Hemisphere
Sample Installation with Envoy and Tripod
