1.4.3 Displaying Tool Information
From Tool Setup menu, select Tool Information and press ENTER. Use UP/DOWN
arrow keys to view information. Record information in case the need to contact customer
service arises.
1.4.4 Program Mode
Used to update scan tool’s software. Instructions will be provided with updates.
1.5 Personal Computer (PC) and Printer Interface
Scan tool is equipped with a standard 9 pin serial interface. Use connection to attach
tool to a PC or compatible printer.
• Personal Computer –
Use serial adapter to connect to a PC when updating to current available software.
Software updates may be purchased from Actron by calling the toll free number
provided.
Refer to Section 2.4.13 Print Data for default serial port settings and to make
changes to settings.
• Printer Connection –
Connect a compatible printer cable to the scan tool and Printer using specifications
below:
- If the printer connector is a 25 pin connector or if the gender is not compatible, an
adapter will be required.
- Adapters are available at most local PC stores or electronics outlets.
- A NULL modem adapter is required to be connected in series with scan tool and
printer cable.
1.6 Replacing the Battery
To replace the 9V battery, do the following:
• Remove screw from back of scan tool case.
• Slide battery cover back to disengage hooks.
• Replace 9V battery and place in compartment.
• Slide battery cover up, making sure hooks engage scan tool case.
• Install screw.
1.7 AC Adapter
The AC power adapter powers the tool when you review codes and print off-vehicle and when
you update the software vial a personal computer. The Scan tool is equipped to accept any
110 Vac–12 Vdc AC adapter with the following specifications.
• 300 mA minimum unregulated wall power adapter.
• Dimensions - 5.5 mm Outside Diameter, 2.5 mm Inside Diameter.
Setup Tool For
1) English/Metric
2)Display Contrast
`3)Tool Information
Tool Information:
`Serial No: 1360447]
SW ID: 86E3H[
HW Ver: 1
POS NEG
