26 9620 Professional OBD II Scan Tool
MAIN MENU |
1) Vehicle Diagnosis
2)Tool Setup [
`3)Tool Self Test
@@@@@@@@@@@@@@@@@@@@
@@@@@@@@@@@@@@@@@@@@
@@@@@@@@@@@@@@@@@@@@
@@@@@@@@@@@@@@@@@@@@
Tool Self-Test|
`1) Display Test
2) Keyboard Test[
3) Memory Test
ENTER To Test. Look
For Missing Spots
In Display. Press
BACK When Done
Tool Self-Test|
1) Display Test
`2) Keyboard Test[
3) Memory Test
Push Button To Test
Key And Display Name
Key:
BAC When Done
4.2.3 One or more modules drops the communication link:
When the OBD II System Tester initially links to
the vehicle, it builds a list of all OBD II compliant
computer modules. If in the course of scanning
the vehicle, a module drops the link, a message
will display.
Answering YES will continue operation without the lost module. Answering NO will try to
restore the communication links to get all modules back to an active status.
4.2.4 Keyboard does not function properly:
• Perform Keyboard Test by entering Self-Test and select Keyboard Test function.
• If the keyboard test shows nothing and you still experience the problem, then
contact Actron Technical Support.
4.3 Tool Self-Tests
Tool Self-Tests are used to test the operation of
the display, keyboard, internal memory, and
printer connection (if applicable).
The Tool Self-Test menu is accessed from the
MAIN MENU. Use the UP/DOWN arrow keys to
select the test and then press the ENTER key.
4.3.1 Display Test
Select Display Test and press the ENTER key. Press ENTER to begin test.
Display Test will fill every pixel of display. Look for
pixels that are not black. Press BACK key to exit
to Tool Self-Test menu. Press BACK key again to
display the MAIN MENU.
4.3.2 Keyboard Test
Keyboard Test checks operation of keys. Select Keyboard Test from Self-Test menu and
press ENTER key. Test screen with instructions is displayed:
Each time a key is pressed , key’s name should
appear on display. For example, if UP arrow is
pressed, screen will display “Key: UP ARROW.” If
name is not displayed, key is not working.
Module ($41) Has |
Stopped Responding.
Continue Without It?
(YES) NO
Push Button To Test
Key And Display Name
Key: UP ARROW
BAC When Done
NOTE: When BACK key is pressed, OBD II System Tester returns to Self-Test Menu, If
not then BACK key is not working.
