9620 Professional OBD II Scan Tool 11
After pressing ENTER from HELP Screen, the
Main Menu displays. Select Vehicle Diagnosis
and press ENTER.
The scan tool asks to erase data from previous
test. Use LEFT/RIGHT arrow keys to select a
response and press ENTER.
A message displays Turn Key Off For 10
Seconds, Then Turn Key On and Then Press
ENTER.
2.3 OBD II Functions List
Use UP/DOWN arrow keys to move cursor(`). Once selection is made, press ENTER.
Press and release BACK key to return to OBD II Function List. Pressing BACK key from
the OBD II Function List returns scan tool to Main
Menu. The first time scan tool communicates with
vehicle, the communication type is automatically
detected, and is used until scan tool is turned
OFF or another vehicle is diagnosed.
Not every vehicle will have every function
listed. If function or part of a function selected is not supported by a vehicle, a
message screen informing of this will be shown.
NOTE: If an Operating Error message is displayed, make sure the OBD II J1962 cable is
securely attached, and ignition key is ON. Cycle ignition key to OFF for 10 seconds,
then ON. This may be required to reset the PCM. If required, select “Yes” to test again.
If problem still exists, refer to Section 4: Help and Troubleshooting Tips.
2.3.1 I/M Readiness
Purpose of the I/M Readiness test is to display current information on emissions-related
systems. These systems are required by OBD II regulation to be monitored for emissions
testing. OBD II I/M Readiness Monitors are strategies designed to test operations of
emission related systems or components. The computer module uses these monitors
to check for correct operations of system and components as well as out of range values.
The computer module may perform a special test on a system or component to complete
the monitor. It may be required to operate vehicle under certain conditions in order to
perform an accurate test. If computer module loses power, or codes are erased, monitors
may be cleared. The scan tool displays the state of vehicle OBD II Monitors.
To enter I/M Readiness viewing mode, select I/M Readiness from OBD II Function List
and press ENTER.
A list of On-Board system readiness tests and
their status will be displayed. Use vehicle service
manuals for more information on emission-
related monitors and their status.
Below are examples of completed versus not
completed I/M Readiness screens:
Use the UP/DOWN arrow keys to view monitor list. The monitor list consists of the OBD
II monitor name followed by monitor state. A monitor that is not supported by test vehicle
MAIN MENU |
`1) Vehicle Diagnosis
2)Tool Setup [
3)Tool Self Test
OBDII Function List |
`1) I/M Readiness
2)Read Codes [
3)Pending Codes
Erase Data From
Previous Vehicle
Test?
YES
Turn Key Off
For 10 Seconds
Then Turn Key On
Then Press ENTER
OBDII Function List |
`1) I/M Readiness
2)Read Codes [
3)Pending Codes
