PRODUCT FEATURES
1. 8 pin PCI-E Connector NEW!!
No Rules Power supplies come with three of the latest 8-pin PCI-E connectors
required for the next generation NVIDIA and ATI graphics cards. These new
defined 8-pin connectors are downward compatible with the existing 6-pin PCI-E
connectors with an 8 pin to 6 pin converter. Thus, with the included three 6-pin/
8-pin connectors, No Rules Power support up to three high-end graphic cards.
2. Excellent Efficiency (up to 87%)
No Rules Power provide excellent efficiency and hence reducing energy
consumption. That in return reduces customers’ electricity bill.
3. 140mm Ball-Bearing Fan
The 140mm ball bearing fan effectively increases the airflow inside the PSU and
decreases the ambient temperature.
4. Extremely good voltage regulation (±3%)
This feature allows tighter load regulation (±3%) than other power supplies (±5%)
and increase system voltage stability.
5. MTBF > 120,000 hours (Highly reliable)
120,000 hours of MTBF (Mean Time between Failures) goes above and beyond all
ATX specifications.
6. Four Independent +12V rails
Four independent +12V rails are provided to support the high-end graphic card
and PC system.
7. Cable Management
Cable Management enables users to remove unused cables and significantly
improves the airflow in the chassis.
8. Industrial grade components (capacitor, transformer, etc)
All components are specially designed for industrial environment and extreme
conditions.
9. Hi-Tech Black Coating
With special Hi-Tech Black coating, No Rules Power looks professional, elegant
and unique.
10. High +5VSB Output
Built-in higher +5VSB (from 2A to 3.5A (PS-ON status)) supports up to 12
USB devices. Also, even the system is power off, USB devices can still be
charged by the 3A sustained output.
