13
SPEC Table
NRP-MC1021
Model NRP-MC1021
SPECIFICATION
Power 1020W
Dimension 150mm(L)x160mm(W)x86mm(H)
Switches ATX Logic on-off additional power rocker switch
Power Factor PF > 0.9
Cooling System 140mm Fan, 2300RPM±10%
Noise 16 dBA at 1300RPM
Efficiency Up to 87%
Hold-up Time 16 ms
INPUT
Input Voltage 100-240VAC
Input Frequency Range 47~63Hz
MTBF 120,000 hrs minimum (at 25℃)
Input Current 100Vac/13A max
Output
Max/Min Regulation *1 Ripple & Noise *2 Output
+5V 30A/0.5A +3, -3% 50mV
180W
+3.3V 30A/0.5A +3, -3% 50mV
+12V1 19A/1A +3, -3% 240mV
864W
+12V2 19A/1A +3, -3% 240mV
+12V3 32A/1A +3, -3% 240mV
+12V4 32A/1A +3, -3% 240mV
-12V 0.8A/0A +9, -5% 120mV 9.6W
+5Vsb 3.0A/0A +3, -3% 50mV 15W
Total Power 1020W
1. +5Vsb operate at 3.0A max load base on PS-ON mode.
If PS-OFF +5Vsb only operate at 3A max load.
2. Add 0.1μF capacitors across output terminal during ripple & noise test.
Environment
Operating Temp. 10℃ to 50℃
Storage Temp. -20℃ to 70℃
Operating Humidity 20% to 90%, non-condensing
Storage Humidity 5% to 95%, non-condensing
Protection
DC Rail Trigger Point/Range
Over Voltage Protection
+3.3V trip point 4.5 Vmax
+5.0V trip point 7.0 Vmax
+12.0V trip point 15.6 Vmax
Over Current Protection Not over 240VA for every output voltage
Short Protection All output to GND
