Quick Reference Guide
3
AL: 2005976-ENG Rev. B / AF: 602-0277-01-B
Task Bar Buttons
Map Screen Icons
Setup Buttons
Home
Map View
Rate Control
AutoSwath
Area Logging Status
Steering Status
NORAC
NORAC Engage Buttons
GPS Status
Map Options
Display Legend
Vehicle Icons
Zoom/Pan Icons
Setup (wrench) Button
Add Button
Remove Button
Guidance
Defi ne guidance
