Quick Reference Guide
2
AL: 2005976-ENG Rev. B / AF: 602-0277-01-B
Mounting the System
28-pin connector
External data card door
Speaker
RAM mount
Connecting the System
Standard System EDGE with OnTrac2 EDGE with ParaDyme
Fuse Type: Blade Style (ATO/ATC)
Rating: J01: 5A, 250 VAC
J03: 15A, 250 VAC
Operating Voltage: 9-16 V DC
A
B A
B
A B C
ECU LO G O
A
B A
B
A B C
A
B A
B
A B C
Jo3
Jo1
}
