Part No. 2002831-39 Rev. D 12
Section 8: Controller Settings
(on Spinner Tab)
The settings shown below appear on the Spinner Tab.
Controller Settings – Spinner Tab
Setting
Name Default
Setting
Description/characteristics
Fan Speed
Cal 4 The number of pulses that are generated by the sensor during one
revolution of the spinner dish.
PWM
Frequency
100 The frequency that the PWM control valve is pulsed at. Settings can
be found from the manufacturer of the valve. Typical settings range
from 100-125 Hz.
PWM
Gain
100 Determines how aggressively the control valve responds when making
spinner speed adjustments. The higher the value the more aggressive
the system response is.
Zero RPM
Offset
30 Represents the maximum duty cycle that is sent to the control valve
without producing any hydraulic flow from the PWM valve. Using too
high of a Zero RPM Offset value can cause the spinner system to not
properly shut off. See the PWM valve manufacturer information for
recommended settings.
Auto
Control
Check Box Default is
unchecked.
Checking the Auto Control check box allows you to control the
spinner speed.
