Brewer Access High-Low User Manual
Page 7

Document # 100452 RevL
7
Printed in USA © 2013
Figure 11. Grab Bar
Note :
Some models may
not have a detachable
power cord.
Foot Control Power Cord
Leveling the Table
A leveling screw pad (Figure 9) is located in six places
under the table’s base and rear cabinet. Adjust the six
leveling pads to achieve a solid, level installation.
Installing the Power Cord
(Models 6001, 6501 and 6801)
1. Remove the power cord from the shipping bag.
2. Insert the female plug end of the power cord into the
receptacle on the table (Figure 10). Make sure the
tabs are aligned and the plug is fully seated.
Note: The power cord is installed at the factory on model
6000, 6500 and 6800.
Installing the Foot Control
1. Insert the male plug of the foot control cord into the
receptacle on the table (Figure 10). Make sure the
pins are properly orientated and the plug is fully
seated.
2. Turn the locking ring clockwise to secure the plug to
the table.
Figure 10 Power Cord and Foot Control.
INSTALLATION (continued)
Installing Grab Bars
1. Remove from drawer.
2. Grab bars fit on either side.
3. Align pin on grab bar shaft with mating slot on side of
table. See Figure 11.
4. Push grab bar all the way down and rotate to front of
table.
5. Push grab bar down until it engages to prevent left or
right movement.
Grab Bar
Mounting Support
Figure 9. Leveling Screw Pad (located under table)
View of underside of base
