Brewer Access High-Low - Manual (Page 13)

Document # 100452 RevL 13 Printed in USA © 2013
Figure 19.
Paper Storage
Figure 20. Side Drawers & Paper Storage
Pass Through Work Surface
A pass through work surface, stored under the seat (Fig-
ure 21), may be pulled out from either side of the table.
Grasp the edge of the work surface and pull until it is fully
extended. Push it fully in to stow after use.
CAUTION
The work surface is intended to support a maxi-
mum of 15 lbs.
Figure 22. Paper Roll Installation
Paper Storage
With the seat back in the upright position, lift the lid on the paper
storage compartment to access stored paper rolls (Figure 20).
Removing the Work Surface for Cleaning
1. Push work surface in, to reveal a white plastic screw.
2. Remove the white plastic screw. (Figure 23.)
3. Pull the work surface toward you and remove it.
4. Reinsert screw after replacing work surface.
CAUTION
Do not use paper roll with a diameter greater than
3” or back rest safety switch will not operate.
Pass Through Side Drawers
Figure 21. Pass Through Work Surface
Figure 23. Location of White Plastic Stop Screw
Plastic Screw
Paper Roll Holder
To change a paper roll, place the paper into the holder
located on the rear of the seat back (Figure 22). Pull
the end of the roll over the top of the seat back and
place in the desired position.
