Free LDEVs: From volumes in the CU selected in the CU drop-down list, volumes that can be specified
as pool-VOLs.
• CU:LDEV: Volume’s CU and LDEV number
NOTE:
An LDEV number ending with # (for example, 00:01#) indicates the LDEV is an external
LU. For more information about external LUs, see the HP StorageWorks External Storage XP user
guide.
• Capacity: Volume’s capacity
• Emulation: Volume’s emulation type
• PG: Parity group to which volume belongs
• CLPR: CLPR number of the CLPR to which volume belongs
• Selected LDEVs: Total number of volumes selected in the list
•
Pool Information: Information about the pool selected in the Pool tree.
• Pool ID: Number identifying the pool
• Status: Pool’s status
• Normal: Pool is in normal status
• Warning: Pool’s usage rate exceeds the threshold
• Blocked: Pool is blocked
• Total Capacity: Pool’s total capacity
• Used Capacity: Pool’s used capacity
• Usage Rate: Proportion of used pool capacity to total pool capacity (%). If the usage rate exceeds
the threshold, Warning appears after the usage rate. If the usage rate reaches 100%, Error
appears after the usage rate.
• Threshold: Threshold for pool usage rate (%)
• Attribute: Software product using the pool
• Snapshot XP: Snapshot XP
• CLPR: CLPR number of the CLPR to which the pool belongs
•
Initialize button: If there is no pool in the array, initializes the whole V-VOL management area. If pools
exist in the array, initializes the pool management block in the V-VOL management area. Initializing
pool management blocks requires up to 20 minutes to complete.
If you click Initialize, all operations performed in the Pool pane, but not applied to the array yet, are
canceled.
•
SIM Complete Request: Completes SIMs related to pools. If you select the check box and click Apply,
SIMs that occurred when a pool’s usage rate exceeded the threshold or when a pool was blocked are
completed. For more information, see ”
•
Apply button: Applies operations performed in the Pool pane to the array. If the specified operations
complete successfully, content displayed in blue italic in the Pool tree or Pool-VOL list change to
normal black.
If an error occurs during operations, error codes and error messages appear in the error message
pane.
•
Cancel button: Cancels all operations performed in the Pool pane.
Creating new pools
The required time for creating pools depends on the number and capacity of pools and pool-VOLs you
add to the pool. If you create many pools or if you add a large-capacity pool-VOL, it might take about
20 minutes at most until the entire processing ends.
1.
Change Command View XP or XP Remote Web Console to Modify mode. For instructions, see the
HP StorageWorks Command View XP user guide for XP Disk Arrays or the HP StorageWorks XP
Remote Web Console user guide for XP12000/XP10000/SVS200.
