Table 8 Full-height server blades in c7000 device bays
• Install 3Gb SAS BL Switches in c7000 interconnect bays 3 and
4
• Attach storage enclosures for these servers to ports 1–4 of the
3Gb SAS BL Switches
If the P700m SAS controller is installed
in mezzanine slot 1:
• Install 3Gb SAS BL Switches in c7000 interconnect bays 5 and
6 or 7 and 8
• Attach storage enclosures for these servers to ports 1–4 of the
3Gb SAS BL Switches
If the P700m SAS controller is installed
in mezzanine slot 2:
• Install 3Gb SAS BL Switches in c7000 interconnect bays 5 and
6 or 7 and 8
• Attach storage enclosures for these servers to ports 5 – 8 of the
3Gb SAS BL Switches
If the P700m SAS controller is installed
in mezzanine slot 3:
3Gb SAS BL Switch User Guide 35
