c7000 recommendations

Table 4 Half-height server blades in c7000 device bays 1–8

Install 3Gb SAS BL Switches in c7000 interconnect bays 3 and
4

Attach storage enclosures for these servers to ports 1–4 of the
3Gb SAS BL Switches

If the P700m SAS controller is installed
in mezzanine slot 1:

Install 3Gb SAS BL Switches in c7000 interconnect bays 5 and
6 or 7 and 8

Attach storage enclosures for these servers to ports 1–4 of the
3Gb SAS BL Switches

If the P700m SAS controller is installed
in mezzanine slot 2:

nl

nl

Table 5 Half-height server blades in c7000 device bays 9–16

Install 3Gb SAS BL Switches in c7000 interconnect bays 3 and
4

Attach storage enclosures for these servers to ports 5–8 of the
3Gb SAS BL Switches

If the P700m SAS controller is installed
in mezzanine slot 1:

Install 3Gb SAS BL Switches in c7000 interconnect bays 5 and
6 or 7 and 8

Attach storage enclosures for these servers to ports 5–8 of the
3Gb SAS BL Switches

If the P700m SAS controller is installed
in mezzanine slot 2:

nl

nl

Table 6 BL2x220c server blades in c7000 device bays 1–8

Install 3Gb SAS BL Switches in c7000 interconnect bays 5 and
6

Attach storage enclosures for these servers to ports 1–4 of the
3Gb SAS BL Switches

“A” servers

Install 3Gb SAS BL Switches in c7000 interconnect bays 7 and
8

Attach storage enclosures for these servers to ports 1–4 of the
3Gb SAS BL Switches

“B” servers

nl

nl

Table 7 BL2x220c server blades in c7000 device bays 9–16

Install 3Gb SAS BL Switches in c7000 interconnect bays 5 and
6

Attach storage enclosures for these servers to ports 5–8 of the
3Gb SAS BL Switches

“A” servers

Install 3Gb SAS BL Switches in c7000 interconnect bays 7 and
8

Attach storage enclosures for these servers to ports 5–8 of the
3Gb SAS BL Switches

“B” servers

Internal mappings and cabling recommendations
