background image

7 Internal mappings and cabling
recommendations

When attaching storage enclosures to SAS ports on the HP 3G SAS BL Switch, use the following
cabling guidelines.

c3000 recommendations

Table 1 Half-height server blades in c3000 device bays

Install 3Gb SAS BL Switches in c3000 interconnect bays 3 and
4

Attach storage enclosures for these servers to ports 1–4 of the
3Gb SAS BL Switches

Install the P700m SAS controller in
mezzanine slot 2 (mezzanine slot 1 is
not supported)

nl

nl

Table 2 BL2x220c server blades in c3000 device bays 1–8

Install 3Gb SAS BL Switches in c3000 interconnect bays 3 and
4

Attach storage enclosures for these servers to ports 1–4 of the
3Gb SAS BL Switches

“A” servers

Install 3Gb SAS BL Switches in c3000 interconnect bays 3 and
4

Attach storage enclosures for these servers to ports 5–8 of the
3Gb SAS BL Switches

“B” servers

nl

nl

Table 3 Full-height server blades in c3000 device bays

Install 3Gb SAS BL Switches in c3000 interconnect bays 3 and
4

Attach storage enclosures for these servers to ports 1–4 of the
3Gb SAS BL Switches

If the P700m SAS controller is installed
in mezzanine slot 2:

Install 3Gb SAS BL Switches in c3000 interconnect bays 3 and
4

Attach storage enclosures for these servers to ports 5–8 of the
3Gb SAS BL Switches

If the P700m SAS controller is installed
in mezzanine slot 3:

nl

nl
