36 Performance Control Export Tool
NOTE: The letters x-y in the CSV filenames indicate a parity group. For example, if the filename is
LDEV_IOPS_1-2.csv
, the file contains the I/O rate for each logical volume in the parity group 1-2.
NOTE:
•
The letters xx in the CSV filename indicate a port name. For example, if the filename is
PortWWN_1A_IOPS.csv
, the file contains the I/O rate for each host bus adapter connected to the
CL1-A port.
• If files are exported to a Windows computer, CSV filenames may end with numbers (for example,
PortWWN_1A_IOPS-1.csv
and
PortWWN_1a_IOPS-2.csv
).
LDEV_D2CR_Trans.ZIP LDEV_D2CR_Trans_x-y.csv
The number of data transfer
operations from disk drives (for
example, logical volumes) to cache
memories in random access mode
LDEV_Response.ZIP LDEV_Response_x-y.csv
The response time of logical volumes
(unit is microseconds 1 )
1. 1 microsecond is one-millionth of 1 second
Table 6 Files containing statistics about ports
ZIP file CSV file Data saved in the file
Port_dat.ZIP Port_IOPS.csv
The number of read and write operations per second
Port_KBPS.csv
The size of data transferred per second (unit is KB/sec)
Port_Response.csv
The response time of ports (unit is microseconds 1 )
1. 1 microsecond is one-millionth of 1 second
Table 7 Files containing statistics about host bus adapters connected to ports
ZIP file CSV file Data saved in the file
PortWWN_dat.ZIP PortWWN_xx_IOPS.csv
The I/O rate (that is, the number of read and write
operations per second) for HBAs that are connected to a
port
PortWWN_xx_KBPS.csv
The size of data transferred per second between a port
and the HBAs connected to that port (unit is KB/sec)
PortWWN_xx_Responsecsv
The response time between a port and the HBAs
connected to that port (unit is microseconds 1 )
1. 1 microsecond is one-millionth of 1 second
Table 5 Files containing statistics about logical volumes in parity, external volume, or V-VOL groups
ZIP file CSV file Data saved in the file
