32
Use the Navigation frame to select an operation in Tiered Storage Manager. When you select an
operation in this frame, the method and information frames display a subwindow that allows you to start
the operation.
Method Frame (section 2-6-3 )
Use the Method frame to select an operation. When you select an operation in this frame, the information
frame displays the associated subwindow. The Method frame may also display a pop-up dialog box.
Information Frame (section 2-6-4 )
This frame displays information required to configure various settings. Information in this frame is
displayed in table format.
Pop-up Dialog Boxes (section 2-6-5 )
Pop-up dialog boxes display additional information you need to add or know to complete an operation.
2-6-1 About the Menu-bar Frame
Use the menu-bar frame to perform operations that affect Tiered Storage Manager as a whole, such as logging
out or displaying version information. When you select a menu item in this frame, the dialog box associated
with the selected item is displayed.
You can use the following menu items from the menu-bar frame:
Tools
Click Tools to display a dialog box that allows you to see another product's window.
Logout
Click Logout to display a logout confirmation dialog box.
Close
Click Close to display a confirmation dialog box from which you can close the browser.
Profile
Click Profile to display a dialog box that provides you with user information.
About
Click About to display information on the product version and license and to register license information.
Help
Click Help to display the Tiered Storage Manager online help.
2-6-2 About the Navigation Frame
Use the navigation frame to select an operation object in Tiered Storage Manager. (These are listed under
Object Tier.) When you select an operation in this frame, the method and information frames display a
subwindow that allows you to start the operation.
Refresh
Click Refresh at the top of the navigation frame to refresh information and re-open the navigation frame.
Tiered Storage Manager
Select Tiered Storage Manager to display a subwindow in the method and information frames that allows
you to start Tiered Storage Manager.
Storage Domains
Select Storage Domains to display a subwindow in the method and information frames that allows you to
start creating and managing storage domains.
Storage Tiers
Select Storage Tiers to display a subwindow in the method and information frames that allows you to start
creating and managing storage tiers.
Migration Groups
Select Migration Groups to display a subwindow in the method and information frames that allows you to
start creating and managing migration groups.
Getting Started with the GUI
